Rated current (A)

6,10,16,20,25,32

No.of pole

1+N

Rated voltage (V)

230

Rated current of frame

32

Rated leakage operating

30

Rated leakage non-operating current

15

Rated leakage breaking time

0.1s

Breaking capacity (A)

3000

Rated current (A)

Rated voltage (A)

Limited time

Pre-engage result

Start state

Note

1.13In

all

t≥1h

Non-trip

Cold state

1.45In

all

t <1h

Trip

Thermal state

The current rises steadily to a fixed value within 5s

2.55In

all

1<t<60s

Trip

Cold state

5In

all

t≥0.1s

Non-trip

Cold state

Open the supplementary switch,connect the power

10In

all

t<0.1s

Trip

Cold state

Open the supplementary switch,connect the power
